Std Pack Size
500
OUR P/N:
OLX7/067-2ERBBA5
Flat Twin & Earth Cable, 2 Core & Earth, 2.5 mm, Stranded Copper, 450/750 Volt, 7/0.67 mm Strands, 2.5 mm Earth Conductor, 12.2 mm x 5.4 mm Overall Diameter, 0.7 mm Insulation Thickness, 1 mm Sheath Thickness, Conductor Resistance: DC: 7.41 Ohm/km, AC: 9.01 Ohm/km, Insulation Resistance: 12 MOhm/km, V-90 PVC Insulation, PVC Sheath, Red Black Green/Yellow Cores, Black Sheath, 90 deg C, AS/NZS 1125, AS/NZS 5000.2
Additional Information
| Brand | Olex |
|---|---|
| Standard Pack Size | 500 |
| UNSPSC Class | 26121600 |
| UOM | MTR |
| Vendor Product | CNCP07A1002BKAA |
| Conductor Type | Stranded Copper |
| Conductor Resistance | DC: 7.41 Ohm/km AC: 9.01 Ohm/km |
| Core Colours | Red/Black/Green/Yellow |
| Insulation Material | V-90 PVC |
| Insulation Thickness | 0.7 mm |
| Insulation Resistance | 12 MOhm/km |
| Overall Diameter | 12.2 mm x 5.4 mm |
| Sheath Material | PVC |
| Sheath Thickness | 1 mm |
| Sheath Colour | Black |
| Standards | AS/NZS 1125 AS/NZS 5000.2 |
| Stranding | 7/0.67 mm |
| Temperature | 90 deg C |
| Voltage | 450-750 Volt |
| Conductor Size | 2.5 mm |
| Number of Cores | 2 Core + Earth |
| Earth Conductor Size | 2.5 mm |
| Product Type | Flat TPS Cable |
